ITU-T G.652.D Single-Mode Optical Fiber

Ultra-Low Attenuation ≤ 0.22 dB/km @1550nm for Long-Distance Telecom Networks

Full Spectrum Transmission from 1260nm to 1625nm

FTTH, 5G Backhaul, Metro Networks, Data Centers & Long-Haul Telecommunications

Description

Low Water Peak Full Band Single Mode Optical Fiber PETROL STEEL CO., LTD is a supplier of ITU-T G. 652.D Single Mode Optical Fiber 652.D Single Mode Optical Fiber / Low Water Peak Full Band Single Mode Optical Fiber to global telecom operators, power communication integrators and EPC general contractors. 652. Low loss, low water peak single mode fiber, compliant with the D/IEC 60793-2-50 Type B1.3 standard. This product is made from high purity quartz preform rods (SiO2≥99.999%) produced by chemical vapor deposition and strict OH- ion control process, and the Peak of water absorption at 1383nm (Zero Water Peak) is removed, so it provides the full-band transmission window 1260nm to 1625nm. It is the preferred transmission medium for long distance backbone networks, metropolitan DWDM systems and FTTx access networks, with typical attenuation of ≤0.18 dB/km (low-loss grade) / ≤0.21 dB/km (standard grade) at 1550nm.

What makes EPC buyers choose PETROL STEEL’s G.652.D low loss optical fiber?
Standard G.652.A/B fibers are not suitable for CWDM multi-wavelength multiplexing due to the high water peak attenuation in the E band (1360–1460nm) that limits the effective bandwidth. Our low-loss G.652.D fiber accurately controls the refractive index profile during the preform deposition by PCVD/OVD processes, minimizes Rayleigh scattering and preserves a polarization mode dispersion (PMD) link design value of PMDQ<=0.06 ps/\\sqrt{km} (typical 0.04). This effectively expands the relay-free transmission distance and reduces the optical amplification nodes, which are crucial for cross-border terrestrial terminals, high-voltage transmission line OPGW companion fibers, and large-scale data center interconnect (DCI) projects.

Your primary concerns as the project material supervisor are generally: geometrical dimensional deviations between batches leading to high fusion splicing losses, suppliers failing to provide traceable optical test reports and delivery delays affecting project milestones. PETROL STEEL has over 20 years of experience in controlling the quality of industrial materials for export, with a 0 claim record in 350+ large scale international projects. Our exported fiber optic cables are 100% tested by bidirectional OTDR and full inspection of geometric parameters, and provided with Mill Test Certificate (MTC), attenuation curve graphs and batch traceability labels for each batch. We also accept and cooperate with any 3rd party inspection designated by clients such as SGS/BV/TÜV to do pre-shipment on-site inspection to make sure every reel of fiber optic cable you received is fully conforming to specification and contract.

Why EPC buyers prefer PETROL STEEL G.652.D Low Loss Fiber Optic Cables? The ordinary G.652.A/B fiber optic cable has a large water peak loss in the E-band (1360-1460nm), and can not support CWDM multi-wavelength multiplexing, which limits the effective bandwidth of the fiber. Our low loss G.652.D fiber optic cable carefully adjusts the refractive index profile and decreases the Rayleigh scattering in the preform deposition stage using the PCVD/OVD method. Also, the design value of Polarization mode dispersion (PMDQ) is maintained at ≤0.06 ps/√km (usually 0.04) to effectively prolong the non-repeater transmission distance and reduce the number of optical amplification nodes. This is vital for cross-border terrestrial terminals, high voltage power line OPGW fiber optics and large-scale data center interconnect (DCI) projects.
As a project material manager you are typically concerned with: Geometric size differences between batches resulting in increased splice loss, suppliers not being able to give traceable optical test results, and supply delays impacting project milestones. PETROL STEEL inherited 20+ years industrial pipe export quality control system. Each and every batch of optical fibers passes 100% bidirectional OTDR testing + complete geometric parameter assessment. We supply with a bilingual Mill Test Certificate (MTC), attenuation curve charts and batch traceability labels. We also accept the third-party organizations such as SGS/BV/TÜV to do on-site pre-shipment inspection, so you can be assured that every reel of optical fiber you receive is fully in compliance with the specification and contract.

Application industries and engineering scenarios of essential
National/Regional Long-Haul Backbone Supports low attenuation and low PMD for 10G/40G/100G/400G DWDM ultra-long span transmission without repeaters, reducing CAPEX for repeater stations.
Metro and FTTx: Full-band availability supports single-fiber GPON/XG PON/NG PON + CWDM, seamless expansion without secondary cabling.
Power Communication & OPGW Cable Integration Great temperature and humidity cycling stability (−60°C to +85°C, Δα ≤ 0.05dB/km) Perfect for fiber optic units of substations and high voltage transmission lines
Data Center Interconnect ( DCI ) and Enterprise Private Networks It is suitable for short-to-medium-haul coherent optical transmission and is compatible with standard LC/SC/ST connector and fusion splice equipment.
Dedicated communication networks for railway, petrochemical and military sectors: Provide high temperature resistant/ UV resistant/ flame retardant special coating versions and long customized reel lengths.

Peter Steel's Inventory, Quality Inspection, and Service Commitment
Peter Steel has long-term strategic cooperation warehouses in major fiber optic industry bases in China, with a stock of multi specification low loss G.652. D bare fiber and colored fiber optic. Standard specifications are arranged for shipment within 72 hours, and large projects can accept batch shipments and long-term planned orders to lock in prices. We deeply understand the three basic principles of "on-time, compliant, and traceable" for engineering materials, and hereby make a written commitment:
Each batch of orders comes with complete quality inspection documents (MTC+OTDR Trace+Geometric Parameter Table+RoHS/REACH Quality Certificate)
Acceptable and cooperative with any third-party inspection agency designated by the customer, such as SGS/BV/T Ü V, on-site or warehouse inspection (Pre Shipment Inspection)
FOB Shanghai/Tianjin/Ningbo or CIF/DAP to the customer's designated destination port, complete set of export documents (CO, PL, Invoice, Packing List)
If both parties confirm that the product quality does not match the agreed specifications or any quality defects, we will unconditionally and fully resend the goods or issue a refund - leaving you with no worries
Based on the supply experience of Peter Steel in delivering over 350 international industrial projects with zero major claims accidents, we can not only provide high-quality fiber optic products, but also offer excellent pre-sales and after-sales services. This is precisely why many international EPC customers insist on and continue to choose PESCO.
