Description
PETROL STEEL CO., LTD is a professional manufacturer of Induction Bend Pipes.
Carbon steel bend piping standard: ASTM/ASME A234 WPB, WPC
Alloy steel bending: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP911, 15Mo3 15CrMoV, 35CrMoV
Stainless steel induction bend: ASTM/ASME A403 WP 304-304L-304H-304LN-304N, ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti, ASTM/ASME A403 WP 321-321H, ASTM/ASME A403 WP 347-347H
Low-temperature steel bending: ASTM/ASME A402 WPL3-WPL6
High-performance steel pipe bend: ASTM/ASME A860 WPHY 42-46-52-60-65-70
Induction Bend Pipes Materials: Cast steel bending, alloy steel bend, stainless steel pipeline bending, copper bending, aluminum alloy bend pipe, plastic bend pipe, PVC pipe bend, PPR bend pipe, RFPP (reinforced polypropylene) pipeline bending, etc.
According to the Induction Bend production technology, it can be divided into hot pushing bending, cold pushing bending, Stamping and welding bending pipe, forging bend piping, casting bending pipe, etc.
According to its radius of curvature, it can be divided into long-radius bending and short-radius induction bending. 'Long radius bend pipe' refers to the outside diameter of the pipe whose radius of curvature is equal to 1.5 times that of the outside diameter, that is, R=1.5D; 'short radius bending pipe' refers to its radius of curvature equal to the outside diameter of the pipe, that is, R=1.0D. (D is the diameter of the bend; R is the radius of curvature).
According to the pressure level, there are about seventeen types, which are the same as the American pipe standards, including Sch5s, Sch10s, Sch10, Sch20, Sch30, Sch40s, STD, Sch40, Sch60, Sch80s, XS; Sch80, SCH100, Sch120, Sch140, Sch160, and XXS; the most commonly used are STD and XS.
https://www.petrolsteel.com/High-Pressure-Flange-p.html
The diameter range we can supply is 8"-100" (219 mm-2540 mm), SCH 40 / STD, API 5L, PSL1, and PSL2 pipes.
Special Applications: Transportation and Distribution Systems
The Production process: high-frequency induced electrical power
Carbon steel bend piping standard: ASTM/ASME A234 WPB, WPC
Alloy steel bending: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP911, 15Mo3 15CrMoV, 35CrMoV
Stainless steel induction bend: ASTM/ASME A403 WP 304-304L-304H-304LN-304N, ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti, ASTM/ASME A403 WP 321-321H, ASTM/ASME A403 WP 347-347H
Low-temperature steel bending: ASTM/ASME A402 WPL3-WPL6
High-performance steel pipe bend: ASTM/ASME A860 WPHY 42-46-52-60-65-70
Induction Bend Pipes Materials: Cast steel bending, alloy steel bend, stainless steel pipeline bending, copper bending, aluminum alloy bend pipe, plastic bend pipe, PVC pipe bend, PPR bend pipe, RFPP (reinforced polypropylene) pipeline bending, etc.
According to the Induction Bend production technology, it can be divided into hot pushing bending, cold pushing bending, Stamping and welding bending pipe, forging bend piping, casting bending pipe, etc.
According to its radius of curvature, it can be divided into long-radius bending and short-radius induction bending. 'Long radius bend pipe' refers to the outside diameter of the pipe whose radius of curvature is equal to 1.5 times that of the outside diameter, that is, R=1.5D; 'short radius bending pipe' refers to its radius of curvature equal to the outside diameter of the pipe, that is, R=1.0D. (D is the diameter of the bend; R is the radius of curvature).
According to the pressure level, there are about seventeen types, which are the same as the American pipe standards, including Sch5s, Sch10s, Sch10, Sch20, Sch30, Sch40s, STD, Sch40, Sch60, Sch80s, XS; Sch80, SCH100, Sch120, Sch140, Sch160, and XXS; the most commonly used are STD and XS.
The more applications of the Induction Bend Pipes: aqueducts steel pipe, channel canals steel pipeline, tunnels steel piping, siphons steel pipe, sewer stele pipes, sewage pipeline, drainage steel pipe, etc.
For more info and price of induction bend pipe specifications, please send us the inquiry; you will get the quick reply soon.
