Description
PETROL STEEL MIG Aluminium Alloy Welding Wires have good ductility and corrosion resistance. Gas welding and argon arc welding of pure aluminum. Good crack resistance and wide application range. Gas welding and argon arc welding of aluminum alloys (except high-magnesium alloys). Corrosion resistance and high strength. Argon arc welding of aluminum alloy.
PETROL STEEL welding wire contains silicon additives to improve the fluidity/wettability of the weld pool. Silicon additives also reduce the susceptibility of welds to cracking, thereby improving durability. The bright welding surface of this aluminum welding wire makes it a popular choice for welders. The welding wire can be used for welding various grades of aluminum and has versatility. Wire diameter: .035. Spool weight: 1 lb. The aluminum used here is 0.035 inches. The welding wire is ER4043 aluminum, which can be used for forging and casting alloys
PETROL STEEL ER4043-Welding Wire-MIG (GMAW)-Aluminum AWS A5.10 Welding position: all, except for the vertical downward introduction: used for welding heat-treatable base alloys and more specifically, MIG with aluminum 5% silicon for 6XXX series alloys Solid welding wire. Unprocessed low-intensity value. Resistant to high-temperature cracks. The main area of use is the weld on cast aluminum. It is not recommended for materials that require anodization. Uses: Material: AlSiMg, AlMgSi. Used for welding 6XXX alloy and most cast alloys, automobile parts, such as frame and driveshaft, bicycle frame. Chemical composition (%): The chemical composition Al-Si-Fe-Cu-Mn requires a balance of 4.5-6.0?0.8?0.3 ?0.05 Typical test results balance 5.12 0.13 0.01 0.01 Chemical composition Mg-Zn-Ti-Be requirements? 0.05?0.1?0.2?0.0003 Typical test results 0.03 0.002 0.007 0.0002 Welding parameters (DC+): diameter WFS (ipm) ampere volts (lb/100 ft) argon (cfh) 0.030 "480-626 60-175 15-24 0.65- 1.25 25-30 0.035" 450-750 70-185 15-27 1.0-4.25 30-35 0.045"330-500 125-260 20-29 1.0-4.25 35-45 1/16" 250-450 170-300 24- 30 3.8-6.6 45-75 Shielding gas: 100% argon, argon/helium mixture The above parameters are for reference only and depend on various factors. Before starting the welding operation, run tests, evaluate, and set welding parameters.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER4043 aluminum filler is a silicon-aluminum type, used for welding of type 6052 and 6063; in some cases, other aluminum also uses this type of welding.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER1070 is a pure aluminum welding wire with an aluminum content greater than 99.5%. It has good corrosion resistance, good conductivity, and advanced nature. It is also the best choice for color matching after anodizing. Recommended model: aluminum alloy 1000. Product use: engine, electric power, chemical industry, food, etc.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER1100 is a pure aluminum welding wire with an aluminum content of more than 99%. It has good corrosion resistance, good conductivity, and advanced nature. It is also the best choice for color matching after anodizing. Recommended model: aluminum alloy 1000. The product can be used for welding in industries such as engine, electric power, chemical industry, and food.
About PETROL STEEL AlMg Welding Wire ER2319, since the composition of copper is between 5.8% and 6.8%, this is a product of the same grade as 2319 that can be used for welding aluminum alloy materials. The scope of application of our products: nuclear industry, shipbuilding, boilers, aerospace industry, etc.
PETROL STEEL AlMn Welding Wire ER3103 is a non-heat-treated forged alloy with a manganese content of 1.2%. Gas welding and arc welding can be carried out easily. The weld metal using this product has higher toughness than pure aluminum, has good corrosion resistance, good weldability, and plasticity in seawater. Welding for: shipbuilding/marine and offshore technology, heat exchangers, aircraft and military components, motor vehicle radiators, pipelines and pipelines, pressure vessels, etc.
PETROL STEEL AlSi Welding Wire ER4043 contains 5% silicon, has good thermal crack resistance, and can be used for welding forging and casting alloys. Product use: welding or surfacing light alloy processing， including the ships, engines, chemicals, food, sports equipment, molds, furniture, containers, containers, etc.
PETROL STEEL AlSi Welding Wire ER4047 is suitable for welding various forged, cast, and extruded aluminum alloys, with low melting points, good fluidity, and avoiding post-welding deformation. Product use: welding or surfacing light alloy processing.
PETROL STEEL AlMg Welding Wire ER5087 is a 5% magnesium alloy welding wire. It is a multi-purpose general welding material. Suitable for welding or surfacing welding of 5% magnesium cast and forged aluminum alloy. It has high strength, good forge ability, and good corrosion resistance. Gender These MIG Aluminium Alloy Welding Wires also provide a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
PETROL STEEL AlMg Welding Wire ER5183 can be used for welding and surfacing of 4.5% magnesium of the same grade, with good welding performance, corrosion resistance, and mechanical properties. Product use: pressure vessels in chemical, nuclear, shipbuilding, boiler, aerospace, and other industries.
PETROL STEEL AlMg Welding Wire ER5356 is widely used in common welding materials with a magnesium content of 5% and can be used for welding or surfacing forging and casting alloy processing. The product has high toughness, good forge ability, and good corrosion resistance. In addition, this is a good choice for color matching after the anode process. Product use: bicycles, aluminum alloy locomotives, etc. Engines, pressure vessels, munitions processing, shipbuilding, space shuttles, etc.
PETROL STEEL AlMg Welding Wire ER5556 is a 5% magnesium alloy welding wire. It is a multi-purpose general welding material. Suitable for welding or surfacing welding of 5% magnesium cast and forged aluminum alloy. It has high strength, good forge ability, and good corrosion resistance. Gender This product also provides a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
PETROL STEEL AlMg Welding Wire ER5754 is a 5% magnesium alloy welding wire. It is a universal welding material with a wide range of applications. Our MIG Aluminium Alloy Welding Wires are suitable for welding or surfacing 5% magnesium cast-forged aluminum alloy with high strength and good forge ability. Has good corrosion resistance. This product also provides a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
PETROL STEEL welding wire contains silicon additives to improve the fluidity/wettability of the weld pool. Silicon additives also reduce the susceptibility of welds to cracking, thereby improving durability. The bright welding surface of this aluminum welding wire makes it a popular choice for welders. The welding wire can be used for welding various grades of aluminum and has versatility. Wire diameter: .035. Spool weight: 1 lb. The aluminum used here is 0.035 inches. The welding wire is ER4043 aluminum, which can be used for forging and casting alloys
PETROL STEEL ER4043-Welding Wire-MIG (GMAW)-Aluminum AWS A5.10 Welding position: all, except for the vertical downward introduction: used for welding heat-treatable base alloys and more specifically, MIG with aluminum 5% silicon for 6XXX series alloys Solid welding wire. Unprocessed low-intensity value. Resistant to high-temperature cracks. The main area of use is the weld on cast aluminum. It is not recommended for materials that require anodization. Uses: Material: AlSiMg, AlMgSi. Used for welding 6XXX alloy and most cast alloys, automobile parts, such as frame and driveshaft, bicycle frame. Chemical composition (%): The chemical composition Al-Si-Fe-Cu-Mn requires a balance of 4.5-6.0?0.8?0.3 ?0.05 Typical test results balance 5.12 0.13 0.01 0.01 Chemical composition Mg-Zn-Ti-Be requirements? 0.05?0.1?0.2?0.0003 Typical test results 0.03 0.002 0.007 0.0002 Welding parameters (DC+): diameter WFS (ipm) ampere volts (lb/100 ft) argon (cfh) 0.030 "480-626 60-175 15-24 0.65- 1.25 25-30 0.035" 450-750 70-185 15-27 1.0-4.25 30-35 0.045"330-500 125-260 20-29 1.0-4.25 35-45 1/16" 250-450 170-300 24- 30 3.8-6.6 45-75 Shielding gas: 100% argon, argon/helium mixture The above parameters are for reference only and depend on various factors. Before starting the welding operation, run tests, evaluate, and set welding parameters.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER4043 aluminum filler is a silicon-aluminum type, used for welding of type 6052 and 6063; in some cases, other aluminum also uses this type of welding.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER1070 is a pure aluminum welding wire with an aluminum content greater than 99.5%. It has good corrosion resistance, good conductivity, and advanced nature. It is also the best choice for color matching after anodizing. Recommended model: aluminum alloy 1000. Product use: engine, electric power, chemical industry, food, etc.
PETROL STEEL MIG Aluminium Alloy Welding Wires ER1100 is a pure aluminum welding wire with an aluminum content of more than 99%. It has good corrosion resistance, good conductivity, and advanced nature. It is also the best choice for color matching after anodizing. Recommended model: aluminum alloy 1000. The product can be used for welding in industries such as engine, electric power, chemical industry, and food.
About PETROL STEEL AlMg Welding Wire ER2319, since the composition of copper is between 5.8% and 6.8%, this is a product of the same grade as 2319 that can be used for welding aluminum alloy materials. The scope of application of our products: nuclear industry, shipbuilding, boilers, aerospace industry, etc.
PETROL STEEL AlMn Welding Wire ER3103 is a non-heat-treated forged alloy with a manganese content of 1.2%. Gas welding and arc welding can be carried out easily. The weld metal using this product has higher toughness than pure aluminum, has good corrosion resistance, good weldability, and plasticity in seawater. Welding for: shipbuilding/marine and offshore technology, heat exchangers, aircraft and military components, motor vehicle radiators, pipelines and pipelines, pressure vessels, etc.
PETROL STEEL AlSi Welding Wire ER4043 contains 5% silicon, has good thermal crack resistance, and can be used for welding forging and casting alloys. Product use: welding or surfacing light alloy processing， including the ships, engines, chemicals, food, sports equipment, molds, furniture, containers, containers, etc.
PETROL STEEL AlSi Welding Wire ER4047 is suitable for welding various forged, cast, and extruded aluminum alloys, with low melting points, good fluidity, and avoiding post-welding deformation. Product use: welding or surfacing light alloy processing.
PETROL STEEL AlMg Welding Wire ER5087 is a 5% magnesium alloy welding wire. It is a multi-purpose general welding material. Suitable for welding or surfacing welding of 5% magnesium cast and forged aluminum alloy. It has high strength, good forge ability, and good corrosion resistance. Gender These MIG Aluminium Alloy Welding Wires also provide a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
PETROL STEEL AlMg Welding Wire ER5183 can be used for welding and surfacing of 4.5% magnesium of the same grade, with good welding performance, corrosion resistance, and mechanical properties. Product use: pressure vessels in chemical, nuclear, shipbuilding, boiler, aerospace, and other industries.
PETROL STEEL AlMg Welding Wire ER5356 is widely used in common welding materials with a magnesium content of 5% and can be used for welding or surfacing forging and casting alloy processing. The product has high toughness, good forge ability, and good corrosion resistance. In addition, this is a good choice for color matching after the anode process. Product use: bicycles, aluminum alloy locomotives, etc. Engines, pressure vessels, munitions processing, shipbuilding, space shuttles, etc.
PETROL STEEL AlMg Welding Wire ER5556 is a 5% magnesium alloy welding wire. It is a multi-purpose general welding material. Suitable for welding or surfacing welding of 5% magnesium cast and forged aluminum alloy. It has high strength, good forge ability, and good corrosion resistance. Gender This product also provides a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
PETROL STEEL AlMg Welding Wire ER5754 is a 5% magnesium alloy welding wire. It is a universal welding material with a wide range of applications. Our MIG Aluminium Alloy Welding Wires are suitable for welding or surfacing 5% magnesium cast-forged aluminum alloy with high strength and good forge ability. Has good corrosion resistance. This product also provides a good color matching for anodized welding. It is used in sports equipment such as bicycles and aluminum scooters, locomotive cars, chemical pressure vessels, ordnance production, shipbuilding, and aviation.
